TĂNG ÂM CÔNG SUẤT VS-34 STK

ÂM THANH BIỂU DIỄN STK

Mã sản phẩm: VS-34 STK

(0 đánh giá) (0 lượt xem)

Model	VS-34
Stereo Mode (both channel driven)	Continuous Average Out put/per CH
FTC @ THD+N=0.1%, f=20Hz~20kHz	Ch1		Ch2
8 ohm/Stereo
4 ohm/Stereo
2 ohm/Stereo
EIA @ THD+1=1%, f=1kHz
8 ohm/Stereo
4 ohm/Stereo
2 ohm/Stereo
Power Bandwidth (Ref. 1kHz, THD+N=0.1%,+0/-1dB)	20Hz~30kHz
THD+N (Ref. 1kHz,f=20Hz~20kHz)	≤0.05%
Frequency Response (Ref. 1kHz, 1watt output, +0/-1dB)	20Hz~40kHz
IMD(SMPTE4:1) (60Hz:7kHz, 4:1 Half power)
4-8 ohm/Stereo	≤0.1%
2 ohm/Parallel	≤0.1%
Crosstalk (RL=8Ω, Half power, Att.Max 600Ω shunt)	≥64dB, 1 kHz
Residual Noise (20Hz~22kHz LPF,Att.min)	≥70dB
S/N Ratio (Filter:A-Weighting, RMS)	≥107dB
Damping Factor (RL=8Ω, f=1kHz)	≥400
Input Sensitivity (Att. max)	AC Switch,Ch1 and Ch2 gain knobs
Rear panel	XLR jack
Output	Speakon Jack
Indicators	Power(Green),Protect(Red),Clip(Red), Parallel(Green),Bar Graph In/Out level
Protection Circuits		1)Short Circuits 2)Current Limit 3)DC detection 4)Thermal 5)Turn On/Off muting 6)Power supply shutdown 7)AC Line fuse
Fan Circuit	Four Fans Variable Low Speed(50℃), High speed(60℃)
Power Consumption (1/3 power)
DIMENSION	480mm X 88mm X 495mm
Weight	16.54 kg
