| Model | VRM-1000K |
| Configuration | |
| Power(EIA) | |
| 4 ohm Load Per Channel | 250 Watts each Channel |
| 8 ohm Load Per Channel | 170 Watts each Channel |
| Bridged 8 ohm | 470 Watts each channel |
| Rated Power(20-20kHz) | |
| 4 ohm Load | 220W x 4CH |
| 8 ohm Load | 150W x 4CH |
| Bridged 8 ohm | 430W x 2CH |
Distortion
(THD & SMPTE IND:20Hz TO 20kHz) | |
| Mic input to Main Mixers Output | 0.01% |
| Mic input to Power Amp Output | 0.05% |
| Inputs(all 1/4” TRS are Bal. / Unbal. except) | |
| Mono Mic/XLR | 2 |
| Stereo Music line A/RCA | 4 L & R |
| Stereo Music line A/RCA | 4 L & R |
| CH Insert | - |
| Tape | - |
| AUX Returns/Sub CH in | 2 TS 1/4" |
| Amp in/ 1/4" TRS Phone Jack | 4 Main Insert |
Outputs
(all 1/4” TRS are Bal. / Unbal. except*) | |
| Main L/R Stereo | 4 GROUP TS 1/4” |
| Main Mono(Subwoofer) | Stereo RCA |
| Aux Sends | 2 RCA for score high & low |
| Tape L/R Stereo | Stereo RCA |
| Phones | - |
| Speaker Outputs | 4 Compression Terminals |
| Channel Strips | |
| Level controls | Yes |
| Constant PAN(Blance) control | Yes |
| 10dB Input PAD | Yes |
| Buss Assign | Yes(Mix to Amp 1-2/3-4) |
| Music Input Select | Yes(A-B) |
| Aux controls | 1 EFX |
| EQ | Yes |
| LED indicators | Sig,Peak |
| Master Section | |
| Digi EFX Program | Dual Variable
1 Rev Control(0.5-2 sec)
1 Dealy Control(50-500 msec)
1 Feed Back Control(0-70%)
1 Delay + Reverb Mixing Control(0-100%) |
| Digi EFX Control | DSP Level Set(Peak, Sig),Bright Control |
| Digi EFX Buss Control | Yes |
| Voice Compression control | Yes |
| Mic Master Level Control | Yes |
| Mic Master Fader Control | Yes |
| Mic Master Pan Control | Yes |
| Effect Send Mic Master | Yes |
| Output Metering Bar Graphic | Yes(1/3,2/4) |
| Main Mic Master Volume | 60 mm Faders |
| Mono Master | Yes(by main mix fader) |
| Power AMP Assign | L(CH 1&2)+R(CH 3&4)Bridge/Stereo |
| Power AMP Clip Limiter SW | Yes, CH1&2 CH3&4 |
| Noise | |
| Master Gains@Unity, CH.gains Down | 87dB |
| Master Gains@Unity, CH.gains@Unity | 85dB |
| Signal to Noise Ratio | ≥89dB |
| Crosstalk | |
| Adjacent inputs or to output | -89dB |
| Frequency Response | |
| 20Hz to 40kHz(Mic Pre Section) | +0, -1.5dB |
| 20Hz to 30kHz(Power AMP Section) | +0, -1.5dB |
| Maximum Levels | |
| Mic Preamp Input | +14dBu |
| Power amp in | 0dBu |
| All other inputs | +14dBu |
| Impedances | |
| Mic Preamp Input | +4 Bal |
| All Other Inputs | 10 k |
| Line Input | 4 k |
| Equalization | 3 Band Mid Sweep(MIC CH) | 5 Band G.EQ(MUSIC CH) |
| Low EQ(±15dB) | 80Hz±15dB | 60Hz, 250Hz |
| Mid EQ(±12dB) | 100Hz-8kHz±12dB | 1 kHz, 3.5kHz |
| Hi EQ(±15dB) | 12kHz±15dB | 12kHz±12dB |
| Low-Cut Filter | 150Hz 12dB/Oct for Mono output |
| Micriphone Preamp E.I.N | -130 dBm |
| Power Requirements | 1300 Watts |
| Dimension(WxHxD) | 483 x 132 x 357 |
| Shipping/CBM | 0.0593 |
| Net Weight | 15 kg |
| Shipping Weight | 17 kg |
